Ledes Conduit Bend Liquid Tight Connector PVC Rigid Electrical Conduit Bends - Grey

Compatible Standard

AS/NZS 2053

EN 61386

UL94

ISO 9001:2015

Ledes AS NZS 2053 Certified Conduit & Fittings

Features

Design for AU Market. Designed for Australian market, 100% compliance project requirements and certified by AS/NZS 2053 and IEC 61386.

Non – Metallic Conduit Bend. Electronic & heat insulation, light weight, long lasting and rustproof. Which are pros comparing with metallic electrical conduit bends.

High Fire Rating. Up to V0 fire rated means the flame will self-extinguishing in 5s after cut off the source of fire for provided the best protection for your home & office.

UV Resistance. Great UV resistance performance for outdoor installed purpose weatherproof electrical pipe fittings and keep long lasting life and save your money.

Trusted Partner. 15+ huge construction projects core supplier over the world and services hundreds of companies in US & CA & AU & UAE & SA.

Full Customized Service. Not only size and colour of products, but we can offer total solutions for your project based on our rich industry experience.

Overview

Ledes Australian standard series electrical conduit bend can be installed with conduit, pulling the wiring through conduits as an electrical fitting. The manufacture of plastic conduit bends seems to be easy, but in fact, it must be takes effort to meet relevant environmental protection requirements.

Starting with raw materials, Ledes resolutely resists the use of recycled materials for reprocessing, and we insist on using 100% brand new materials for production. In addition, we use high-quality additives and auxiliaries imported from the United States to ensure that product performance can always best. At the same time, in the production process, we strictly follow the production process to produce qualified products. The quality department controls the quality based on production line station inspections and random inspections of finished products to ensure that the products are qualified before we shipped to customers.

In addition, Ledes has launched high freedom customized service. Not only the conventional color, wall thickness and other parameters, but we can also design and mold products according to customer requirements to 100% meet customer needs.

Product Description

Why You Need AS/NZS 2053 & IEC Certified 45 & 90 Degree Bends?

Design for AU Market

We have experienced designer team for developing different kind of electrical conduits and accessories, and the rigid conduit bend based on customer needs of Australia. Comply with relevant standards.

Non - Metallic Conduit Fittings

In addition to lightweight and cost effective, plastic electrical conduit fittings are also rust-proof and insulated. Considering the PVC is natural insulator, which can ensure the safety of your life and property in an accident.

High Fire Rating

Ledes PVC conduit bend with V0 fire resistance rating can be self-extinguished in 5s after cutting off the fire source, which greatly improved the safety of life and property.

UV Resistance

Extreme UV Exposure, perfect match with outdoor installation and suitable for extremely harsh outdoor conditions.

Performance

Raw Material

PVC

Colors

Grey, Orange or Customized

Waterproof Rating

IP65

Temperature Range

-15℃ to +105℃ (5 to 221℉)

Electrical Characteristics

Electrical Insulated

Fire Rating

V0

Resistance to UV

Extreme Resistance to UV Radiation

Properties

ITEM NO

ID

OUTER PACKING

UNIT

QTY

LE-SWBY20

20

CTN

180

LE-SWBY25

25

CTN

135

LE-SWBY32

32

CTN

100

LE-SWBY40

40

CTN

35

LE-SWBY50

50

CTN

28

LE-SWBY63

63

CTN

Customized

LE-SWBY80

88.9

CTN

Customized

LE-SWBY100

114.3

CTN

Customized

LE-SWBY125

140

CTN

Customized

LE-SWBY150

160

CTN

Customized

Remarks: can be customized thickness and color
