Ledes Type EB Rigid PVC Electrical Conduit Underground Pipe

Compatible Standard

UL 651 Listed

ASTM1784-20

Ledes - UL Listed Electrical Conduit Supplier

Features

UL Listed: Experience the peace of mind that comes with knowing your type EB electrical conduit pipe & fittings are UL listed, ensuring safety and quality. Get in touch with us for more information.

Branded Product: Made with 100% brand new materials, this conduit is smooth on the inside and out, perfect for effortless wire running.

High Fire Rating: UL 94V-0 fire rating guarantees no flaming out when cut off from the fire source, safeguarding your home and building.

Non-Metallic Pipe: Heat-, corrosion-, fire-, sunlight-, and rust resistance are just some of the benefits of type A & EB conduit.

Trusted Partner: With 15+ huge construction projects core supplier experience and services to 1,000+ companies in US, CA, AU, UAE, and SA, you can trust our commitment to excellence.

Overview

Ledes Type EB PVC conduit and fittings, when buried in concrete trenches outside of buildings, can be used with wiring rated at 90°C (194°F). These conduit and fittings serve as rigid nonmetallic conduit for wires and cables, following the National Electrical Code. Specifically, Type EB (encased burial) PVC conduit is designed for encasement in concrete in trenches outside of buildings.

As a prominent supplier of plastic PVC electrical conduit pipes in China, Ledes has been shaping the industry for over 14 years. Proudly standing as the 1st PVC electrical pipe manufacturer in China to pass UL & CSA certification, Ledes is committed to delivering top-tier safety and innovation.

Our Schedule 40 & 80 electrical conduits and Type A & EB PVC rigid pipe series represent the pinnacle of design and manufacturing. crafted using the latest technology and formulas, these pipes are engineered to meet even the most stringent standards and proudly bear a UL 94V-0 fire rating, ensuring rapid fire extinguishing within 5 seconds of the fire source being cut off. Additionally, they withstand continuous operation at a scorching temperature of 90°C (194°F), guaranteeing worry-free performance.

But Ledes doesn’t stop there. We’ve revolutionized the industry by offering a new generation of customized services for customers worldwide. Say goodbye to limited options like regular colors and wall thicknesses. Ledes goes the extra mile, offering unmatched design and mold production tailored to perfectly meet your project requirements. From conception to completion, Ledes is your trusted partner in delivering the highest quality electrical conduit pipes that empower safety and efficiency.

Product Description

Why You Need Ledes Type A & EB PVC Rigid Electrical Conduit?

Design for US Market

Ledes Type A & EB PVC rigid electric conduit and fittings offer up to 5,000 psi tensile strength and have a deflection under load of ≤0.25mm, which fully complies with the UL 651 standard. With an experienced design team on hand, we’re able to develop various electrical conduits and accessories tailored to your specific needs. Trust in our products that are based on UL, NEMA, CSA, and other relevant standards.

Branded Product

Streamline your pre-installation time and cost savings with our premium Type EB PVC rigid electrical conduit, crafted with 100% brand-new materials.

High Fire Rating

Ledes Type EB PVC Rigid Electric Pipe, boasting a UL 94V-0 fire resistance rating, significantly enhances safety of life and property by self-extinguishing within 5 seconds of cutting off the fire source.

Non - Metallic Conduit

In addition to being lightweight and cost-effective, plastic Type EB PVC rigid electric conduit is also rust-proof and insulated. However, over time, the wire tube can rust and corrode, which can lead to injury to people.

Sunlight Resistance

Experience exceptional heat and sunlight resistance for outdoor installations, ensuring longevity and saving you money in the process.

Performance

Tensile Strength

4,000 lbf/in2 (2.76 kN/cm2)

Extrusion

Fusion

Water Absorption

﹤0.50% of Whole Weight After Soak

Resistance to Crushing

ID≥70% After Test

Resistance to   Impact

Less Than 3 of 1/32 inch Cracks &   Tears

Deflection under Load

﹤0.25mm (0.010   inch) Deformation

Fire Rating

UL 94V-0

Resistance to Specific Reagents

Less ±2.50% Weight After 60 / 120 Days Soak

Permanency of Printing

Yes

Rust & Sunlight Resistant

Yes

Color

Grey or Customization

Material

PVC

Customization Services

Available

Place of   Origin

Dongguan, China

Shipping

By sea

Samples

Available

Length

10ft or 20ft.

Markings

Information to be marked on conduits,

a) The phrase “rigid PVC conduit,

b) The trade size of the conduit product,

c) The name or trademark of the manufacturer or any other distinctive marking by means of which the organization responsible for the product can be readily identified

d) The date or other dating period of manufacture not exceeding any three consecutive months.
For an elbow the date of manufacture is to be the date that:

1) The conduit is extruded when both extrusion and bending occur at the same location or
2) The elbow was formed, where the conduit is extruded at a different location.

f) All markings shall be repeated at uniform intervals and shall appear at least every 10 feet (3 m), but not less than once, on each straight length of PVC conduit.

g) Type A and Type EB rigid PVC conduit and rigid PVC elbows shall additionally be marked “underground only – encase in concrete.”

Properties

Size(in)

Part No.

OD(in)

T(Max)

2

LE-TPEB01

2.375

0.094

3

LE-TPEB02

3.500

0.109

3-1/2

LE-TPEB03

4.000

0.124

4

LE-TPEB04

4.500

0.129

5

LE-TPEB05

5.563

0.144

6

LE-TPEB06

6.625

0.164

Remarks: can be customized thickness and color

Standards

Purpose

Price List

Get the full price list now by contact our sales team.
